Multivac R530 640mm Dual Seal
Manufacturer:
Multivac
Type:
R530
Year Built:
2005
Working Hours:
11000
This used Multivac R530 Thermoformer is built in 2005. On the PLC in the machine is standing 11000 operating hours. The machine has a film width of 640mm and there is a dye set on the machine with an exit of 960mm. The format is now divided in a 5.2 format. The machine is equipped with 2 formats. These formats can be used for Soft Folie packaging. The format does not have a stamp. The frame of the machine is currently 10800mm long, but we can always adjust this to the dimension you need.
Machine details
- Type under foil unwinding: Jumbo.
- Type top foil unwinding: 76mm core.
- The machine has 4 QRP cuts.
- The machine is equipped with a Cassette Undercut length cutting.
- For the process the residual foil is a Roll-up wheels on this machine.
- The products come from the machine on a None.
Other features of the machine
- Vacum option
- Gas flushing
- label option
- Forming Pump
If you wish, you can contact us more photos or information.
